Core Application Scenarios

• General-Purpose Signal Analysis — Up to 44GHz flexible testing

• Millimeter-Wave Validation — Cost-effective mmWave measurements

Technical Adaptation for Rental Scenarios

• Test Throughput Optimization — Fast sweep reduces measurement time by 50%

• Versatile Configuration — X-Series applications support multiple test requirements

High-Speed Analysis Architecture

Features "Multi-Engine Processing + Adaptive Scanning" design: Dual DSP cores enable simultaneous signal processing and measurement calculations (sweep speed ≤20ms for full span, Estimated from signal analyzer standards). Integrated PathWave X-Series applications provide standardized measurement workflows (phase noise, noise figure, analog demodulation). List-sweep mode supports ≤1ms point-to-point switching (Estimated from product specifications).

Signal Analysis Workflow

1. Configuration: Select measurement application from PathWave X-Series

2. Setup: Define frequency points using list-sweep mode

3. Execution: Initiate fast sweep for spurious response detection

4. Analysis: Evaluate small-signal performance using DANL/TOI metrics

Millimeter-Wave Measurement Boundary

Cable phase stability may cause ±5° error when testing >40GHz (Estimated from mmWave test characteristics). Mitigation: ① Use phase-stable test cables; ② Enable vector error correction.
