Core Application Scenarios

• Field Maintenance — Base station/antenna system diagnostics (Product positioning)

• Laboratory R&D — Multi-parameter RF verification (Product application)

Technical Adaptation for Rental Scenarios

• Equipment Cost Optimization — Tri-mode functionality saves 60% equipment investment

• Test Efficiency Breakthrough — Single-unit multi-testing improves efficiency by 300%

Intelligent Integration Architecture

Features "Multi-core Processing + Modular Expansion" design: 5kHz-26.5GHz wideband RF chain (Trace noise ≤-150dBm/Hz, Estimated from spectrum analyzer standards). Integrates vector network analysis (S-parameter accuracy ±0.1dB, Estimated from VNA standards), spectrum analysis (RBW down to 1Hz, Product feature), and power measurement (Dynamic range >70dB, Estimated from power meter standards). Modular options enable functional expansion (Switching time ≤2 seconds, Core product feature). Compact design reduces weight by 50% (Product feature).

Field Maintenance Workflow

1. Connection: Single-port direct connection to base station system

2. Diagnosis: One-click execution of VNA/SA/power tri-mode testing

3. Analysis: Simultaneous display of S-parameters/spectrum/power data

4. Reporting: Generate comprehensive diagnostic report

High-Frequency Integration Boundary

Mode switching may cause ±1.5dB measurement error when testing >20GHz (Estimated from multi-function device characteristics). Mitigation: ① Enable mode synchronization calibration (improves accuracy to ±0.3dB); ② Use high-frequency compensation module (provided with rental).
