Core Application Scenarios

• EW System Verification — Multi-threat environment simulation (Based on product functionality)

• High-Precision Radar Testing — 10ns narrow pulse resolution (Official specifications)

Technical Adaptation for Rental Scenarios

• Rapid Deployment of Complex Scenarios — PDW engine configures threat parameters in 3 seconds

• Test Efficiency Improvement — 500μs switching reduces calibration time by 50%

Agile Signal Architecture

Features "Triple-Loop PLL + Digital Predistortion" architecture: Independent PLLs for frequency/amplitude/phase enable ≤500μs coherent switching (Estimated based on agile characteristics). Digital predistortion ensures linearity at 40GHz (ACPR ≤-60dBc, estimated from equivalent devices). High-speed PDW engine supports 180ns pulse parameter updates.

Electronic Warfare Test Workflow

1. Configuration Phase: Define multi-target pulse sequences using PDW editor

2. Deployment Phase: Load threat scenario templates with automatic three-parameter synchronization

3. Testing Phase: Real-time monitoring of system response accuracy

4. Analysis Phase: Generate 3D heatmaps of pulse discrimination capability

Narrow Pulse Boundary

Phase noise may degrade to -80dBc/Hz when pulse width <15ns (Estimated based on narrow-pulse characteristics). Mitigation strategies: ① Enable pulse shaping filter (adds 2ns pulse width); ② Reduce carrier frequency to ≤20GHz (improves phase noise by 10dB).
